EAB-B100 series Rotary air bearing stages

•Cleanroom compatible

•Can be mounted vertically or horizontally

•direct-drive, rotary air-bearing stages

•Analog and digital position feedback

Product overview

Delivers best-in-class rotational motion, helping you to optimize your high-precision process

Minimizes axial-, radial-, and tilt-error motions, reducing the need for extensive post-processing of parts and

measurement data

Offers excellent positioning performance and velocity stability with high-resolution feedback

Features a novel, non-influencing motor design that contributes to ultra-precise motion performance

Provides generous load-carrying capacity without compromising on motion quality

Integrates easily into precision systems and machines due to compact, lightweight form factor, as well as horizontal and

vertical mounting and load-carrying capabilities

Product Detail

The motorized rotation stages are designed for accuracy, precision, high stiffness, and ease of use, and can

be mounted in any orientation.

Various options can be combined to create a solution ideal for point-to-point indexing or constant velocity scanning.

The E-ART160 stages offer superior travel accuracy, flatness, and wobble performance. Because they are friction free

and require no maintenance or lubrication, they are ideal for use in cleanrooms.

•torque motor

•Brushless

•Slotless

•Low cogging torque

•Analog and digital position feedback Absolute encoder (optional)

Absolute encoders supply explicit position information that enables immediate determination of the position.

Therefore, no referencing is necessary when switching on and this increases efficiency and safety during operation.

•Accessories and options

•Encoder

•Optional tip/tilt platform

•Custom mounting flanges

•PIglide filter and air preparation kits

•Single or multi-axis motion controllers and servo drives

•Base plates made of granite and systems for reducing vibration

•Application field
